The SK45SRX-7 Kobelco excavator is a mini excavator with a cab and an operating weight of 10,300 pounds. It has a 37 horsepower Yanmar diesel engine.
The maximum digging height of a standard arm is 18 feet 10 inches, the maximum depth of the ground is 18 feet 8 inches, and the maximum digging depth is 11 feet 3 inches.
A new hydraulic system at mini excavator cuts the digging cycle by 7% compared with the previous 6e series and does not slow down. The redesigned travel motor increased travel speed by 5% . Other benefits of the new hydraulic system include smoother operation and better leveling performance. The integrated flow pump system enables the operator to take advantage of the additional output of the third pump, which would otherwise drive the swing and bulldozer circuits. This extra output is pointed to the arm and prospers when the extra power is tapped, resulting in fast and smooth operation even when overloading.
The KOBELCO sk45srx-7 is a small mini excavator with a standard arm 5 feet 1 inch long. It has a pre-installed thumb holder.
The standard 2-way dozer blade comes with a float, the blade is designed so that when dozing, the ground falls forward, not behind the blade.
Inside the cabin, the bulldozer can be controlled with ergonomically designed levers that are easier to grip, and the first and second speed switches have been repositioned to improve maneuverability.
The boom, boom, and swing bracket all have large cross-sectional sections to increase connection strength, and the bolt fastening pins lock the boom firmly to prevent the top of the boom from opening laterally. The bucket uses cast-iron idler wheel connecting rod and box type bulldozer bracket provides greater strength.
The Mini Excavator series comes with a standard 3-year or 3,000-hour warranty.
KOBELCO SK45SRX-7 Specs
- Operating weight: 10,300 lb.
- Max dig depth: 11 ft. 3 in.
- Power: 37 hp
- Max digging height: 18 ft. 10 in.
- Max reach, ground: 18 ft. 8 in.
